AMPLIFI Alien Tri-Band Gigabit Router and MeshPoint Kit

Combination pack with AmpliFi Alien Router and Amplifi Alien MeshPoint.
- 6,000 ft² coverage
- 120+ connected devices
WiFi6 (8x8 MIMO)
MeshPoint with (1) GbE LAN port
Router with (4) GbE LAN and (1) GbE WAN port
Router with 4.7" LCM touchscreen

Hardware
Processor Quad-Core ARM® Cortex® A53 at 2 GHz
Memory Router/MeshPoint: 1 GB
Management Interface AmpliFi WiFi App
Networking Interface - Router: (1) GbE RJ45 WAN
(4) GbE RJ45 LAN
- MeshPoint: (1) GbE RJ45 LAN
Power Method Router/MeshPoint: Universal AC Input: 100–240V AC, 1A Max., 50/60 Hz
Max. Power Consumption - Router: 35W
- MeshPoint: 34W
ESD/EMP Protection Air/Contact: ± 24kV
Antenna Gain
- 2.4 GHz 3 dbi
- 5 GHz 6 dBi
Max. TX Power
- 2.4 GHz 20dbi
- 5 GHz 36 dBi
MIMO
- 2.4 GHz 4 x 4
- 5 GHz 8 x 8
Speeds
- 2.4 GHz 1148 Mbps
- 5 GHz 4800 Mbps
Antenna Router/MeshPoint: Internal Dual-Band Metal Stamp with 12 Polarity
Display - Router: 4.7" Diagonal, 274 x 1268, 279 ppi, G+F Touch, Full Color
- MeshPoint: No Display
LEDs Router/MeshPoint: Green Ring
- MeshPoint: Green Status Indicator
- Flashing: Initial Conguration
- Lights up in Sequence Bottom to Top: Bootup in Progress
- Lights Up in Sequence from the Middle Outwards: Wi-Fi Not Ready or Connected
- Steady: Device is Adopted (Lit based On the Signal Strength Receiving from the Router)
- Flash Quickly: Locate
- Lights Up One by One: Firmware Upgrading
Button Router/MeshPoint: Factory Reset
Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC
