Right Power Automatic Transfer Switch (ATS) ATS 16A

Topology: Relay
Input
Voltage Range: 220/230/240 VAC
Acceptable Input Voltage Range: 180 - 258 VAC
Input Frequency: 50 Hz/60 Hz
Maximum Input Current: 16 A
Output
Output Voltage: 220/230/240 VAC
Maximum Output Current: 10 A for IEC-C13 outlets
16 A for IEC-C19 outlet
Connection
Input 2 x IEC-C20
Output: 8 x IEC-C13 & 1 x IEC C19
Communication: USB/RS-232
Transfer Time: 9~12ms (Typical), 16ms, Max
Physical
Operating Humidity: 0-95 % RH @ -5°C~ 45°C (non-condensing)
Dimension (D x W x H (mm)): 330 X 430 X 44
Net Weight (kg): 5
Net Weight (including accessories)(kg): 8
