HP DL380 G7 2U Server 8xSFF - Refurbished
HP Proliant DL380 Gen7
-Intel Xeon X5650 2.667Ghz/3.067Ghz(Turbo) 6C/12T
-16GB (2x8GB) DDR3 RDIMM
-2x 300GB (8x2.5” hard drive bays )
-HP SmartArray P410i Controller
-4x 1GE, 2x NC382i Dual Port Multifunction Gigabit Adapters
-HP 750 W Common Slot High Efficiency Power Supply
-1 Year Part Exchange Warranty
Technical Specs:
| Processor(s) | Intel Xeon E5606 2.13Ghz, 8MB, 4C/4T |
| Chassis | Chassis with up to 8 x 2.5" Hot Plug Hard Drives |
| Memory | 16GB (2x8GB) DDR3-RDIMMM 1600Mhz |
| Hard Disk | 300GB SAS 10k RPM 2.5 |
| Storage Controller | HP SmartArray P410i Controller |
| Network Controller | 4x 1GE, 2x NC382i Dual Port Multifunction Gigabit Adapters |
| Power Supply | HP 750 W Common Slot High Efficiency Power Supply |
| Warranty | 1Yr Part Exchange |
HP ProLiant DL380 Generation 7 (G7)
The HP ProLiant DL380 G7 Server continues to deliver on its heritage of engineering excellence with increased flexibility and performance, enterprise-class uptime and HP Insight Control manageability, 2 socket Intel® Xeon® performance, and 2U density for a variety of applications.
Processors:
Up to 2 Six-Core or Quad-Core Intel® Xeon® processor 5600/5500 sequence)
Intel® 5520 Chipset
Memory:
Total of 18 DIMM slots
Up to 192 GB (16 GB kits populating12 DIMM slots), using PC3-8500R DDR3 Registered (RDIMM) memory, operating at 800MHz when fully populated at 2 DIMMs per Channel in 12 slots
Up to 48 GB, using PC3-10600E DDR3 Unbuffered (UDIMM) memory, operating at 1066MHz when fully populated at
2 DIMMs per Channel in 12 slots
Two DIMMs Per Channel at 1333MHz supported with ROM update via ROM Based Setup Utility (RBSU) for 1333MHz
RDIMMs. UDIMM support is only on 12-slot servers.
Storage Controller:
Entry Models: HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
Base Models: HP Smart Array P410i/256 MB Controller (RAID 0/1/1+0/5/5+0)
Performance Models: HP Smart Array P410i/1G FBWC Controller (RAID 0/1/1+0/5/5+0)
High Efficiency: HP Smart Array P410i/Zero Memory Controller (RAID 0/1/1+0)
Available upgrades: 1G FBWC, 512MB FBWC, 256MB, 512MB with BBWC, Battery kit upgrade (for the 256MB
cache), and Smart Array Advanced Pack (SAAP)
Internal Drive Support:
Standard (8) small form factor (SFF) hot-plug drive bays to support Serial-attached SCSI (SAS) and Serial ATA (SATA)
drives
Optional second drive cage for additional (8) SFF drive bays (total 16)
Optional cage for (6) Large Form Factor SAS/SATA hard drive bays
Slimline media bay supporting Optical Drive (ships standard on performance models)
NOTE: The Optical Drive option is not available when you upgrade with the additional 8 SFF drive cage, or in the LFF
Models
Network Controller:
Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total) with TCP/IP Offload Engine,
including support for Accelerated iSCSI
Expansion Slots:
Up to six available PCI-Express Gen2 slots, optional mixed PCI-X / PCI-Express or x16 PCI configurations available (see
"Standard Features -Expansion Slots" section for more details)
Ports:
USB 2.0 support, 5 total ports: (2) ports up front; (2) ports in back; (1) port internal
1 internal Secure Digital (SD) slot
Redundancy:
Fully redundant hot plug fans (N+1)
Hot plug power supply with optional redundancy (Included in Performance models)
Power Sources:
Dual Common Slot Bay for Right Sized, Hot plug and Redundant Power options
HP 1200W CS Platinum Power Supply (optional)
HP 750W CS HE Gold Power Supply (standard on some models)
HP 460W CS HE Gold Power Supply (standard on some models)
HP 1200W -48V DC Power Supply (optional)
Infrastructure Management:
Convenient slide-out Systems Insight Display for quick and easy front view server diagnostics, along with status LEDs,
Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU)
HP Integrated Lights-Out (iLO) for ProLiant provides simplified server setup, health monitoring and recovery, power and
thermal control, and lights-out remote administration.
HP Insight Control a product option, delivers essential infrastructure management that can help save time and money
by making it easy to deploy, migrate, monitor, control and optimize your IT infrastructure through a single, simple
management console. Insight Control supports both Windows and Linux-based central management servers.
HP Insight Dynamics for ProLiant, a product option, is an integrated command center that enables IT Staff personnel to
continuously analyze and optimize a converged infrastructure, while automating and reducing the cost of common data
center tasks by as much as 40 percent. This ultimately enables them to dynamically keep pace with the organization's
changing business requirements.
Form Factor:
HP ProLiant DL380 Generation 7 (G7)
Rack (2U), (3.5-inch); Depth 27.25 inches (69.98 cm)
Operating Systems and Virtualization Software Support for ProLiant Servers:
Supports Windows, RHEL, SLES, OEL, Solaris, VMware, and Citrix XenServer
