CPU:
Intel® Socket 1150 for 4th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Supports Intel® 22 nm CPU
Supports Intel® Turbo Boost Technology 2.0
Chipset: Intel® H81
Memory:
2 x DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Due to Intel® chipset limitation, DDR3 1600 MHz and higher memory modules on XMP mode will run at the maximum transfer rate of DDR3 1600 Mhz.
Expansion Slots:
1 x PCIe x16
2 x PCIe 2.0 x1
Storage:
Intel® H81 chipset :
2 x SATA 6Gb/s port(s), yellow
2 x SATA 3Gb/s port(s), dark brown,
Supports Intel® Rapid Start Technology, Intel® Smart Connect Technology *1
USB Ports:
Intel® H81 chipset: 2 x USB 3.1 Gen 1 port(s) (2 at back panel, blue)
Intel® H81 chipset: 6 x USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)
Form Factor:
uATX Form Factor
8.9 inch x 7.2 inch ( 22.6 cm x 18.3 cm )
